AtmosFX Fan 8E DMX-Controlled Stage Fan
AtmosFX Fan 8E provides three fan speeds, 0-220° airflow direction adjustment and DMX control for stage effects. The product photograph shows the unit without the optional FA-800H mounting bracket.
Brand:
RayGlimz
Spu:
AtmosFX Fan 8E
Appurtenance:
Introduction
Product Overview
AtmosFX Fan 8E provides three fan speeds, 0-220° airflow direction adjustment and DMX control for stage effects. The product photograph shows the unit without the optional FA-800H mounting bracket.
Key Features
- Three speeds: 1100 / 1300 / 1400 rpm.
- 0–220° direction adjustment.
- 1-channel DMX control.
- Stated maximum airflow of 82 m³/min.
Technical Specifications
| Brand | RayGlimz |
|---|---|
| Model Code | AtmosFX Fan 8E |
| Power Consumption | 820 W |
| Power Supply | 230 V, 50 Hz |
| DMX Channel Modes | 1 CH |
| Fan Speeds | 1100 / 1300 / 1400 rpm |
| Direction Adjustment | 0–220° |
| Stated Maximum Airflow | 82 m³/min |
| DMX Connections | 3-pin XLR |
| Dimensions Without Bracket | 490 × 390 × 490 mm (L × W × H) |
| Weight Without Bracket | 14 kg |
| Optional Mounting Bracket | FA-800H |
